Cavity

Blade Fuse

Cartridge Fuse

Description

F36

–

–

Not Used

F37

–

50 Amp Red

Radiator Fan PWM Con-

troller

F38

–

–

Not Used

F39

–

40 Amp Green

HVAC Blower Motor

F40

–

–

Not Used

F41

–

50 Amp Red

Voltage Stability Module

(VSM) #1 – If Equipped

With Stop/Start Engine

Option

F41

—

60 Amp Yellow

Body Controller Module

(BCM) – Feed 1

F42

–

–

Not Used

F43

20 Amp Yellow

–

Fuel Pump Motor

F44

–

–

Not Used

622 MAINTAINING YOUR VEHICLE
