Chrysler 2015 200 - Owner Manual User Manual
Page 622
Cavity
Blade Fuse
Cartridge Fuse
Description
F16
20 Amp Yellow
–
Powertrain / Ignition
Coil
F17
–
–
Not Used
F18
–
–
Not Used
F19
–
40 Amp Green
Starter Solenoid
F20
10 Amp Red
–
A/C Compressor Clutch
F21
–
–
Not Used
F22
5 Amp Tan
–
Radiator Fan Enable
F23
70 Amp Tan
–
Body Controller Module
(BCM) – Feed 2
F23
50 Amp Red
–
Voltage Stability Module
(VSM) #2 – If Equipped
With Stop/Start Engine
Option
F24
–
–
Not Used
620 MAINTAINING YOUR VEHICLE
