4-5-3. Scan Direction
Scanning begins in the direction that corresponds to
the direction that the TUNING control was last turn­
ed, or with respect to which of the microphone
UP/DWN switches was last depressed. If you press­
ed the UP switch before initiating scan, scan will pro­
ceed in a positive direction. If the DWN switch was
pressed scan will tune down in frequency.
4-5-4. Scan Hold
The transceiver will stop on a busy channel and then
resume after a 5-second delay. You must cancel
scan operations to remain on the channel.
4-5-5. Memory Channel Lockout
The Memory Channel Lockout function allows you to
temporarily skip unwanted Memory Channels during
the Memory Channel Scan mode.
1. Press the VFO/M key to select the Memory
Channel mode.
2. Select the Memory Channel that you want to
skip using the TUNING control or the UP/DWN
switches.
Display +
-
Model - { * )
TM-221 series + 600 kHz -600 kHz
TM-321A -M.6 MHz -1.6 MHz
TM-421A + 5 MHz -5 MHz
TM-421ES
European
market
*-1.6 MHz *-7.6 MHz
U.K.
market
+ ^ . 6 MHz -1.6 MHz
TM-521A + 12 MHz -12 MHz
TM-521E + 35 MHz -6 MHz
3. Press the M.IN key and then the SCAN key.
Whenever the M.IN key is pressed, the M in­
dicator will turn on. You must complete the
desired action within 5 seconds, or the M in­
dicator will turn off. If the indicator goes off, you
must press the M.IN key again. A star (★ ) will
appear to the left of the Memory Channel
Number. This indicates the Memory Channel will
be skipped during scan operations.
4. To cancel the Memory Channel Lockout press
the M.IN key and then the SCAN key.
4- 5-6. Priority Alert (TM-221ES/421ES only)
Memory Channel 1 will be checked at approximately
5- second intervals to check for activity. If the fre­
quency is occupied, a beep will sound. If the audio
confirmation function has been turned off, no beep
will sound, even if Memory Channel 1 is busy.
Pressing the ALERT key will switch this function off
and on.
Note: ----------------------------------------------------------------------------
The alert function will not work when the RC-10 is
connected to the TM-221 ES/421 ES.
4-6. REPEATER
4-6-1. Transmitter Offsets
All amateur radio repeaters utilize a separate receiver
and transmitter section. The receiver frequency may
be either above or below the transmitter frequency.
For most repeater's offsets are as follows:
TRANSMITTER OFFSET FREQUENCY
This transceiver allows you to store the frequency,
and offset direction in Memory Channels 0 — 9, and
A —b, or you can select these functions directly from
the keyboard.
(With the TM-221 A/321 A)
The TM-221 A/321 A have been programmed accor­
ding to the standard ARRL Band Plan, regarding
transmitter offsets. Please see the enclosed charts
for additional information. You can, of course, over­
ride this by using the SHIFT function, if desired.
With the TM-221 A
144.00 145.10 145.50 146.00 146.40 146.60 147.00 147.40 147.60 148.00 (MHz)
S
—
s + s
—
+ s
—
S: Simplex Channel
With the TM-321A
220.000 223.940 224.995 (MHz)
S: Simplex Channel
