4-2-2.

Frequency

and

Memory

Channel

Selec­

tion

The desired operating frequency and the Memory
Channel may be selected by using either the TUNING
control or the microphone UP/DWN switches. Press
the VFO/M key to alternate between the VFO and
the Memory Channel modes.

4-2-3. Frequency Step Selection

The frequency step can be selected by using the

following procedure:

1. Press the VFO/M key to select the VFO mode.

Press the M.IN key and then the REV key.

Whenever the M.IN key is pressed, the M in­
dicator will turn on. You must complete the

desired action within 5 seconds, or the M in­
dicator will turn off. If the indicator goes off, you

must press the M.IN key again.
Select the desired frequency step using the TUN­
ING

control

or

the

microphone

UP/DWN

switches. The figure below shows how the TUN­
ING control and UP/DWN switches will increase

or decrease in size.

2

.

3.

Turn the TUNING control

counterclockwise or press

the microphone UP switch.

With the TM-221A

-------25kHz-----------

■5kHz-

Turn the TUNING control

clockwise or press the

microphone OWN switch.

--------------------10kHz----------

-20kHz-

-15kHz-

With the TM-221ES

-------25kHz-------------

-12.5kHz-

-5kHz-

-20kHz-

With the TM-321A

-------15kHz------------

-15kHz-

-20kHz-

-10kHz-

-25kHz-

•10kHz-

-5kHz-

Wlth the TM-421 series

------ 20kHz------------------------25kHz-

■12.5kHz-

15kHz-

With the TM-521 series

Í

12.5kHz

I_________________

-10kHz-

-25kHz

-5kHz

-20kHz-

1

10kHz

_J

4, To return to the normal receive frequency, press

any key except the LOW or the POWER
switches, or turn the TUNING control.

4-2-4. ALT (Auto Lock Tuning) System (TM-521

series only)

The ALT system operates similar to an AFC

(Automatic Frequency Control) system. This system
is useful when the frequency of either station starts

to drift. When this occurs distortion of the signal is
the usual result. The ALT system will correct for this

apparent drift.

(Example)

Frequency

Transmit Frequency Receive Frequency
of the Distant Station

|ALT System is[

performed.

Frequency

Transmit Frequency Receive Frequency
of the Distant Station

Note:-----------------------------------------------------------------------------

The frequency display will not change, even though
the receive frequency might shift in order to properly
tune the incoming signal. When the ALT system is
operating the Direction indicator will turn on if the
system shifts the receiver frequency. The Direction
indicator will show you if the incoming signal was

higher or lower than the displayed frequency.

Turns on when the transmit
frequency of the distant sta­
tion is higher than your receive

frequency.

n

c

n n

I d B f.Ji U U

^

Oi

_^y_!

MmM

□□□□□□□□□□□□□□

S&Rf

Turns on when the transmit
frequency of the distant sta­
tion is lower than your receive

frequency.

To utilize this feature:

(With the TM-521 A)

1.

Press the M.IN key. The M indicator will turn on

for 5 seconds.

2.

While the M indicator is on press the SHIFT key.

If you do not press the SHIFT key while the M in­

dicator is on you will have to start over at step
one. The ALT indicator will turn on and the

receiver will automatically center itself on the in­
coming signal.

M.IN key

M indicator

'/Fo/M M. N MH, KENWOOD izooMHg

fm

transceiver

tm

-

szia

n r n n

r

i £ B I . 2 U U

L

[EBl □□□□□□□□□□□□[/]□ 1

★ P

j

SHIFT

REV SCAN

cress

TONE

3. To release the ALT system, press the M.IN key

and then the SHIFT key. The ALT and the Direc­

tion indicators will turn off.

12
