I N S T A L L A T I O N
Connect the telephone line________________
Connect one end of the telephone line cord to the jack labeled LINE on the back
of the fax machine. Connect the other end to a modular wall jack.
Attach the document support______________
Attach the document support as shown in the illustration below.
Document
support
Special Line Considerations______________
Roll Over Phone Lines
A roll over phone system is a group of two or more separate telephone lines that
pass incoming calls to each other if they are busy. The calls are usually passed
down or “rolled over” to the next available phone line in a preset order.
Your fax machine can work in a roil over system as long as it is the last number
in the sequence, so the call cannot roll away, Do not put the fax machine on any
of the other numbers; when the other lines are busy and a second fax call is
received, the fax call is transferred to a line that does not have a fax machine.
Your fax machine will work best on a dedicated line.
