Kenmore 141.15227 - Manual (Page 8)

Parts List
REF# DESCRIPTION PART# QTY REF# DESCRIPTION PART# QTY
1.
Stainless Steel Lid P01A1A
1
46. Rear Panel P4356A
1
2. Lid Side Panel - Left P0164A
1
47, Door Bracket P4413A
1
3. Lid Side Panel - Right P0163A
1
48. Door Panel P4357A 2
4. Temperature Gauge P0615D
1
49. Door Handle P0271A 2
5. Lid Handle P0251A
1
50. Magnetic Door Stop P5589A 2
6. Heat-Insulating Spacer P5573A 2 51. Tank Pull-Out Tray P4043A
1
7. Name Plate P0468A
1
52, Bracket for Tank Pull-Out Tray P40438
1
8. Secondary Cooking Raok -PorcelainP1521E
1
53, Slide P55J8A 2
9. Cooking Grid - Porcelain P1661A 2 54. Caster P5111B 4
10. Flame Tamer - Porcelain PI 749A 2 54a Customized Wrench P55F5A
1
11. Main Burner P1935F 4 55. Caster Seat P4528A 4
12. Main Burner Bracket P2230A
1
56. Tool Holder P80F5A
1
13. Gas Collector Box w/ Electrode P2618A 2 57, Tool Hook P80F6C 5
14. Ignition Wire Set P2637B
1
58. Side Burner Lid P0199A
1
15. Electric Ignitor P2503G
1
59. Pot Support P80F7A
1
16. Smoker Drawer Bracket P80F3A
1
60. Side Burner Electrode P2627A
1
17. Smoker Drawer P80F4A
1
61, Side Burner P1959A
1
18. Bowl Panel - Left P0799A
1
62, Gas Valve for Side Burner P32D1B
1
19. Outside Bowl Panel - Left P0755C
1
63. Extension Tube for Side Burner P3983G
1
20. Bowl Panel - Right P07A1A
1
64. Regulator and Hose P3632P
1
21. Outside Bowl Panel - Right P0758C
1
65. Reinforcing-Bracket for Grill Bowl P80P1A
1
22. Bowl Panel - Front P0759B
1
66. Manual Lighting Stick P5540B
1
23. Bowl Panel - Rear P0760C
1
67. Heat Shield for Grease Tray P80P6A
1
24. Wind Shield P80F2A
1
68, Tightening Tool P55M3A
1
25. Grease Draining Tray P2755A
1
— Owner's Manual P47B7E
1
26. Grease Receptacle P2741A
1
— Hardware Pack P55K5A
1
27. Gas Manifold P5038A
1
— Hardware Pack A P55L3B
1
28. Gas Valve for Main Burner P32C1B 4 — Hardware Pack B P55K5C
1
29. Heat Shield for Control Panel P2999A
1
30. Protective Pad - Heat Resistant P80L5A 2
For the repair or replacement parts you need:
Call 6 am -11 pm CST, 7 days a week
31. Control Panel P2966A
1
1 -800-366-PART
n-800-366-7278)
32. Decorative Front Cover P2965A
1
33. Control Knob P3430A 5 To make sure you obtain the correct replacement
34. Back Burner Assembly PI 948A
1 parts for your Kenmore gas grill, please refer to
the part numbers on this page. The following
35. Gas Valve for Back Burner P32C1C
1
information is required to assure you receive the
36. Fitting for Back Burner Valve P39A2A
1
correct parts:
37. Electrode for Back Burner P2648A
1 1. Grill Model Number (see CSA label on grill)
P39A7A
1
2. Part Number
38. Orifice
3. Part Description
39. Extension Tube for Back Burner P39A8A
1
4. Quantity of parts needed
40. Control Knob for Back Burner P3430D
1
41. Side Shelf P1147A
1 Important: Keep this Owner's Manual for convenient
referral and for part replacement.
42. Side Burner Frame P1174A
1
43. Bottom Shelf P1074A
1
Important: Use only Sears authorized parts. The
44. Cart Leg -Left P0856A
1 use of any part that is not Sears authorized can
45. Cart Leg -Righ P0857A
1
be dangerous and will also void your product
warranty.
Customer Service Helpline: If you have questions about assembly or if there are damaged or missing parts when
you unpack this unit from the shipping box, call us Sam - 8pm CST,Monday through Friday at:
1 -888-317-7642
