Configuring Source Address Traps 6-9
Source Addressing
Module- and Port-level Traps
To set module- and port-level source addressing traps, select the appropriate
channel in the Repeater Source Address window, then click on
to
enable and disable module-level traps, or on to enable and disable
port-level traps.
As with repeater-level trap status, a status of Other for any module indicates that
there is some combination of enabled and disabled source address traps on the
ports in that module.
To configure trap status for all ports on a selected module or modules:
1. In the Module Source Address Traps window ( Figure 6-3 , next page), click
mouse button 1 to select the module for which you wish to enable or disable
traps. If the Set Trap Status For field displays
Selected Modules (the default
setting), you can click to select any modules; to de-select any highlighted
module, click on it again. If the selection
All Modules is displayed in the Set
Trap Status For field, all available modules will be automatically selected; if
you de-select any module, the Set Trap Status For field will automatically
revert to the
Selected Modules setting. To change the setting in the Set Trap
Status For field, click mouse button 1 on the currently displayed setting, and
drag down to select a new setting.
2. Click on the appropriate selection in the Trap Status field to enable or disable
traps for the selected modules, as desired.
3. Click on to save your changes. Note that enabling or disabling
traps at the module level will eliminate any module status of Other by setting
all ports on the selected module or modules to the same status.
NOTE
It is not necessary to close the Source Address List before launching the module and port
traps windows; just move the Source Address List window out of the way, if necessary, to
reach the main Repeater Source Address window.
