Cabletron Systems EMM-E6 - Manual (Page 75)

6-1
Chapter 6
Source Addressing
Displaying the Source Address list; setting the Aging Time; selecting the Hash Type; effects of Source
Address Locking; configuring Source Address traps; finding a Source Address
Displaying the Source Address List
The Source Address List, or Table (SAT), contains the MAC address and its
associated vendor name for each device communicating through a port in the
EMM-E6-controlled hub. Each detected source address is also identified by the
module and port through which it is communicating with the EMM-E6.
To view a EMM-E6’s Source Address List:
from the icon:
1. Click on the appropriate EMM-E6 icon to display the icon menu.
2. Drag down to Source Address and release.
from the Hub View:
1. Click on to display the Device menu.
2. Drag down to Source Address and release.
from the command line (stand-alone mode):
1. From the appropriate directory, type
spmarun r4sa
