Monitoring Hub Performance 2-25
Using the EMM-E6 Hub View
Protocols/Frames Statistics
The Protocols/Frames statistics windows display the following fields:
Protocols
• OSI Frames
• Novell Frames
• Banyan Frames
• DECNet Frames
• XNS (Xerox Network Systems) Frames
• IP Frames
• Ctron Frames
• AppleTalk Frames
• Other Frames
Frame Sizes
• Runt Frames (packets smaller than 64 bytes)
• 64-124 (byte) Frames
• 128-255 Frames
• 256-511 Frames
• 512-1023 Frames
• 1024-1518 Frames
• Giant Frames (packets larger than 1518 bytes)
Viewing the Port Source Address List
The Port Source Address List accessible via the port-level menus displays the
MAC address and its associated vendor name for each device communicating
through a specific port in the EMM-E6-managed hub.
To view a port’s Source Address List:
1. Click mouse button 3 in the appropriate Port Status or Port Index box to
display the Port menu.
2. Drag down to Source Address List, and release.
NOTE
For more detailed information about error statistics and the possible network conditions
they represent, consult the Cabletron Systems Network Troubleshooting Guide,
included with this package.
