Stabilizer and fin mounting – Carl Goldberg GPMA1926 Monster Pitts Electric ARF User Manual
Page 8
8
1.
Collect the following items.
(1) stabilizer
(1) right elevator
(1) left elevator
(1) fuselage
(1) wing
(1) wing bolts 6-32 x 1-1/4”
(1) elevator joiner wire
(6) CA hinges
Stabilizer and Fin
Mounting
Caution:
install the elevator joiner wire first.
2.
Slide the elevator joiner wire into the slot for the
stab. You cannot install it after the stab is in
place without cutting the fuselage.
