6
10. Drill a 1/16” in the outer most hole of the four
control horns on the bottom wing and install
one of the servo connectors.
11. Center your servo with the radio and install the
z-bend into the servo arm. Put the other end
into the servo connector and center the
aileron. Tighten the set screw.
12. Repeat for the other aileron.
Caution:
Make sure the nylon nut is pushed all the
way onto the pushrod connector.
Landing Gear
1. Collect the following items.
(1) Main landing gear
(4) 4-40 x 1/2” bolts
(4)flat washers
1. Install the gear in the slots on each side of the
fuselage and align the holes. Install the four
4-40 bolts with flat washer into the blind nuts
that are per-install in the fuselage. Be careful
and don’t press to hard trying to get the
screw started or you could push the blind nut
out of the hole. Be sure to use lock-tite on
the bolts.
