11
Elevators and Rudder
Mounting
1. Install both elevator halves on the elevator
joiner wire and hinges and check the align-
ment. Both should be level. If not bend the
joiner wire till they match.
2. Remove the elevators and put some epoxy
glue into the holes where the elevator joiner
wire fits. Reinstall the elevators.
3. Deflect the elevator to it full travel in one
direction and make sure to hold the elevator
firmly against the trailing edge of the stab.
Apply a drop of Ultra Set thin CA to each
hinge. Turn the plane over and deflect the
elevator in the other direction and apply a
drop of glue to each hinge.
4. Locate the rudder and tail wheel assembly.
5. Glue the wire into the slot in the bottom of the
rudder using epoxy.
6. Install on of the control horns on the left side
of the rudder in the holes provided. Install the
plate on the opposite side and glue in place
with Ultra Set thin CA.
