Installer Guide 8
Room Temperature ...................... Displays the current room temperature
Lock Mode Indicator ................... Indicates if the thermostat is locked
Set Temperature .......................... Displays the current set point temperature
Service Indicators ...................... Displays various service/maintenance information
Time of Day ................................. Displays the current time of day
Program Event Indicator.............. Displays the program event
Day of the Week ........................... Displays the current day of the week
System Status Indicator ............. Displays information about the status of the system
Hold Mode Indicator ................... Indicates if the thermostat is in HOLD mode
Fan Indicator ................................ Indicates when the system fan is running
Low Battery Indicator .................. Indicates when the batteries need to be replaced
Quick Reference Instructions ...... Stored in slot located at top of thermostat
SpeedBar
®
................................... Increases or decreases settings (time, temperature, etc.)
Reset Button ............................... Resets current time, program and user settings
Battery Compartment ................. Located in the back of thermostat
3 Quick Reference
1
2
3
10
4
14
6
5
7
13
8
9
11 12
1
2
3
4
5
6
7
8
9
10
11
Thermostat Display
12
13
14
Thermostat
