15 Installer Guide
Warning
Read Before Testing
• Do not short (or jumper) across terminals on the gas valve or at the heating or cooling system control board
to test the thermostat installation. This could damage the thermostat and void the warranty.
• Do not select the COOL mode of operation if the outside temperature is below 50º F (10º C). This could
possibly damage the controlled cooling system and may cause personal injury.
• This thermostat includes an automatic compressor protection feature to avoid potential damage to the
compressor from short cycling. When testing the system, make sure to take this delay into account.
NOTE: The compressor delay can be bypassed by pressing the reset button on the front of the thermostat.
All user settings will be returned to factory default, however all Installer settings will remain as originally
programmed in section 4.
1 Touch the SYSTEM TouchPad™ until the thermostat is in HEAT mode.
2 Using the SpeedBar
®
raise the set temperature a minimum of 3 degrees above the current room
temperature. The system should start within a few seconds. With a gas heating system, the fan may
not start right away.
3 Touch SYSTEM until the thermostat is in the OFF mode. Allow the heating system to fully shut down.
4 Touch SYSTEM until the thermostat is in the COOL mode.
5 Using the SpeedBar lower the set temperature a minimum of 3 degrees below the current room
temperature. The system should start within a few seconds (unless compressor short cycle protection
is active – See note above).
6 Touch SYSTEM until the thermostat is in the OFF mode. Allow the cooling system to fully shut down.
7 Touch FAN until the thermostat is in FAN ON mode. The system fan should start within a few seconds.
8 Touch FAN until the thermostat is in FAN AUTO mode. Allow the system fan to turn off.
9 If the thermostat is controlling auxiliary equipment such as an economizer (5320 only), etc., adjust the
thermostat settings to test these devices.
5 System Testing
