Wiring Diagrams
9
R G W/Y
Typical 3-Wire Heating System or Cooling System with Fan Control
Heat or Cool
Control
Fan
Control
24 Volt AC
Transformer
120
Volt AC
Hot Side
Transformer
Typical 2-Wire 24 Volt AC or 250mV - 750mV Millivolt Heating Systems
R G W/Y
Heat
Control
24 Volt AC
Transformer
or Thermopile
120
Volt AC
Hot Side
Transformer
Store this
booklet for
future reference
TWO YEAR LIMITED WARRANTY: Braeburn Systems LLC warrants each new Braeburn thermostat against any defects that are due to
faulty material or workmanship for a period of two years after the original date of purchase by a professional service technician. This
warranty and our liability does not apply to batteries, nor does it include damage to merchandise or the thermostat resulting from accident,
alteration, neglect, misuse, improper installation or any other failure to follow Braeburn installation and operating instructions.
Braeburn Systems LLC agrees to repair or replace at its option any Braeburn thermostat under warranty provided it is returned postage
prepaid to our warranty facility in a padded carton within the warranty period, with proof of the original date of purchase and a brief
description of the malfunction. This limited warranty does not include the cost of removal or re-installation.This warranty gives you specific
legal rights and you may also have other rights that vary from state to state or province to province. Answers to any questions regarding our
limited warranty may be obtained by writing our corporate offices.
Warranty Facility: Braeburn Systems LLC
Attn: Warranty Department
2215 Cornell Avenue
Montgomery, IL 60538
©2010 Braeburn Systems LLC • All Rights Reserved • U.S. Patent 7,438,469 and other patents pending • Made in China • 1005NCS-100-005
