4
Default Thermostat Settings
Function Status after Clear
Operation mode OFF, Auto Changeover enabled
Temperature hold Permanent and temporary hold cleared
Fan Switch AUTO
Clock 12:00 pm, Monday
Room temperature display 70° F (21.0° C), to be renewed within
5 seconds
Set point temperature 62° F (17.0° C) for Heat, Emergency
Heat and Off 83° F (28.0° C) for Cool
Temperature scale Fahrenheit
Operating program DAY program, Monday
Low-battery warning Off, to be renewed within 5 seconds
AC interrupted warning Off, to be renewed within 5 seconds
1st stage differential .5° F (0.2° C)
2nd stage differential 2° F (1.0° C)
Programming 7 Day, 4 Event
Deadband 3° F
Residual Cooling Fan Delay 60 seconds
Short cycle protection timer On, 5 minutes, Reset
Adaptive Recovery Mode ON
Output relays All turned off
Recirculating Fan Timer reset, with 24 min OFF, 12 min ON,
Lock OFF
Extended Hold Long (indefinite)
Filter Check Monitor 0 days-No Warning, Timer reset
Keypad Lock Complete (level 2), unlocked,
555 universal code
System type Conventional, Single Stage
1st Stage Heat Fan Control Gas
2nd Stage Heat Fan Control Electric
Fossil Fuel Compressor Lock Off
Auto Changeover Enabled
Compressor Outage Protection Off, Timer reset
Temperature Sensor
Internal
12 / 24 Hour Clock 12 hour
Adjustment Limit from Set point 0, OFF
AC Interrupt Warning Mode
OFF
User Profile Residential
5
Setting Thermostat Installer Options
Function Status after Reset
Programming Default setting depending on
programming mode setting (see User
Manual). For manual mode: Heat - 62° F,
Cool - 83° F.
Clock 12:00 pm, Monday
1st stage differential .5° F (0.2° C)
2nd stage differential 2° F (1.0° C)
(if configured for Multi-Stage)
Filter Check Monitor
0 days-No Warning
Adjustment Limit from Set point 0, OFF
Keypad Lock
555 universal code or last code entered
Temperature Hold Permanent and temporary hold cleared,
reset to Long Hold
Short Cycle Timer Reset
Recirculating Fan Timer reset, 24 minute off cycle.
With recirculating lock set, fan state
defaults to CIRC.
Programming Installer Settings
4
cont.
Programming Installer Settings
4
When the User RESET button (on front of thermostat) is pressed, the following
options will reset to the factory defaults. All other settings are saved when the
RESET button is pressed.
The Installer Options section allows the system and programming parameters
to be set up at installation. The Installer Options mode is menu driven. As the
different options are programmed you may eliminate specific options. For example,
if the system is set to single stage heat pump, Option 8, selecting the first stage
fan control will no longer be available.
The Installer Option mode is entered by holding the RETURN and buttons
together for 3 seconds. Installer Option 1 Residential or Commercial will be
displayed. Pressing the or buttons will scroll between choices. To scroll to
the next installer option, press the
RETURN button. The thermostat will return to
normal operating mode after the last Installer Option mode has been set or by
pressing the
RETURN and PROG buttons at the same time.
NOTE: The thermostat will return to normal operating mode automatically after
30 seconds if no key is pressed.
NOTE: Any changes to Installer Option 7 (System Type) will cause Options 8, 9, 10,
11 and 12 to reset to the default values that are dependent on system selection.
At initial power up or after Installer CLEAR is pressed, the thermostat is reset to
factory defaults. Installer CLEAR is located on the circuit board.
