6 BGC258 Series CE Approved Gas Valve Installation Instructions
Technical Specifications
Product BGC258 Series CE Approved Gas Valve
Types of Gas 2nd (Natural Gas), and 3rd (LP Gas) Family Gases
Permissible Ambient
(Surface) Temperature
-29 to 79
°C (-20 to 175°F )
Electrical Ratings 12 VDC, 0.875A
25 VDC, 0.46A
25 VAC, 50/60 Hz, 0.42A
120 VAC, 50/60 Hz, 0.088A
240 VAC, 50/60 Hz, 0.044A
Maximum Operating
Pressure North America:
Europe:
Australia: 1/2 psi
50 mbar
5 kPa
Maximum Differential
Pressure
20 mbar (2 kPa [8 in. W.C.])
Reverse Pressure Rating 50 mbar (5 kPa [20 in. W.C.]) Class B (EN 126 and 161); Class 2 (AG 209 and AG 214)
Regulator Classification Class C (EN 126); Adjustable, Class 3, Grade 20 (AG 209)
Regulator Adjustment
Range Bottom Adjust Regulators:
Top Adjust Regulators 7.5 to 12.5 mbar (0.75 to 1.25 kPa [3 to 5 in. W.C.])
22.5 to 30 mbar (2.25 to 3.0 kPa [9 to 12 in. W.C.])
7.5 to 12.5 mbar (0.75 to 1.25 kPa [3 to 5 in. W.C.])
22.5 to 30 mbar (2.25 to 3.0 kPa [9 to 12 in. W.C.])
Body Connections 3/8 or 1/2 NPT, 3/8 or 1/2 BSPP (Thread ISO 7-Rp) or 3/8, 1/2 BSPT (Thread ISO 7-Rc) with
Flange Connection Holes (M4 x 0.7 mm pitch x 6 mm deep)
Valve Torsion Group Group 2 (EN 126 and 161)
Pressure Connection 1/8 BSPP (Thread ISO 7-Rp), 1/8 BSPT (Thread ISO 7-Rc),
1/8 NPT Left-hand and/or Right-hand, or M5 x 0.8 Thread Bottom
Pilot Connection 1/8 BSPP (Thread ISO 7-Rp), 1/8 BSPT (Thread ISO 7-Rc),
1/8 NPT Left-hand and/or Right-hand, or 1/4 in. cc Fitting Bottom
Dirt Strainer 0.9 mm (0.036 in.) mesh (CE only or upon request)
Operating Time Rating 100% Continuous
Valve Timings Closing Time:
Opening Time:
Dead Time: < 1 Second
< 1 Second
< 1 Second
Power Rating 10.5 VA per Coil (except 25 VDC, 11.5 VA)
Electrical Connection 2-Tab Solenoid Coil: 2 x 6.35 mm (1/4 in.)
3-Tab Solenoid Coil: 2 x 6.35 mm (1/4 in.) + 6.35 mm (1/4 in.) Earth Ground
Coil Insulation Class Class F
Packaging Bulk pack supplied to original equipment manufacturer (individual pack optional).
Bulk Pack Quantity 30 per carton
Bulk Pack Weight 35 kg (77 lb) per carton
Accessories Conversion Kits Natural gas to LP gas:
LP gas to Natural gas:
Regulated to non-regulated: GM-70-CLP
GM-70-CNG
BG-70-CBP
