6 BGA Series Shutoff Gas Valve Installation Instructions
Technical Specifications
Product BGA Series Shutoff Gas Valve
Types of Gas Natural Gas or LP Gas
Maximum Operating
Pressure 0.5 psi
Permissible Ambient
(Surface) Temperature -20 to 175ºF (-29 to 79ºC)
Body Connections 1/4, 3/8 or 1/2 cc; 1/8, 1/4, 3/8, 1/2, 3/4 or 1 NPT; 1/8, 1/4, 3/8 or 1/2 BSPP
Electrical Ratings BGA158/BGA171
12 VDC, 0.875A
25 VAC, 50/60 Hz, 0.42A; 25 VDC, 0.46A
120 VAC, 50/60 Hz, 0.088A
240 VAC, 50/60 Hz, 0.044A BGA110
12 VDC,1.0A
25 VAC, 50/60 Hz, 0.595A; 25VDC, 0.675A
120 VAC, 50/60 Hz, 0.13A
240 VAC, 50/60 Hz, 0.063A
Pressure Connections 1/8 NPT left, right, left and right, left/right and bottom, or bottom;
1/8 BSPP (Thread ISO 7-Rp) left, right, left and right, left/right and bottom or bottom; or None
Pilot Connections 1/8 NPT left, right, or left and right; 1/8 BSPP (Thread ISO 7-Rp) left, right, or left and right; or None
Operating Time Rating 100% Continuous
Valve Timings Closing Time ≤1 Second; Opening Time ≤1 Second; Dead Time <1 Second
Power Ratings BGA158/BGA171 10.5 VA per Coil (except 25 VDC 11.5 VA)
BGA110 15 VA per Coil (except 25 VDC, 17 VA)
Electrical Connections 3-Tab Solenoid Coil, 2 x 1/4 in. (6.35 mm) + 1/4 in. (6.35 mm) Earth Ground
2-Tab Solenoid Coil, 2 x 1/4 in. (6.35 mm)
Valve Torsion Group Group 2 (EN 161)
Coil Insulation Class Class F
Packaging Bulk pack supplied to original equipment manufacturer individual pack optional).
Bulk Pack Quantity 40 or 80 depending on the valve size
Bulk Pack Weight BGA158 56 lbs (26 kg), BGA171 48 lbs (22 kg), BGA110 56 lbs (26 kg)
Agency Listing CSA Certificate Number 229521-1656058
UL Recognized File Number MH5939
Specification
Standards UL Standard 429
Standards Complying with EMC Directive
Standards Complying with Low Voltage Directive
ANSI Standards Z21.21
Canadian Standards CAN1-6.5
Performance specifications are nominal and conform to acceptable industry standards. All agency certification of BASO products is performed
under dry and controlled indoor environmental conditions. Use of BASO products beyond these conditions is not recommended and may void
the warranty. Product must be protected if exposed to water (dripping, spraying, rain, etc.) or other harsh environments. The original
equipment manufacturer or end user is responsible for the correct application of BASO products. Consult BASO Gas Products LLC for
questionable applications. BASO Gas Products LLC shall not be liable for damages or product malfunctions resulting from misapplication or
misuse of its products.
Refer to the BGA158, BGA171, and BGA110 Series Shutoff Gas Valve Product Bulletin (BASO-PB-BGA) for necessary information on
operating and performance specifications for this product.
