BGH2UNCTRLHT-01 Universal Hot Surface Ignition Control Installation Instructions
Table 1: BGH2UNCNTRLHT-01 Universal Cross Reference
Switch
Positions
ON
Switch
Positions
OFF
White-Rodgers Robershaw Honeywell Fenwal
1,5 2,3,4
50E47-40 to 49
50E47-240 to 249
―
―
―
1,4 2,3,5
50F47-50 to 59
50F47-250 to 259
―
―
―
1,4,5 2,3
50F47-40 to 49
50F47-240 to 249
―
―
05-356265-151(a,g)
05-356265-152(a,g)
1,3 2,4,5
50E47-70 to 79
50E47-270 to 279
50F47-70 to 79
50F47-270 to 279
HS780-34NL-304A(c)
S89H1003(c)
S89G1005(c)
―
1,3,5 2,4
50E47-60 to 69
50E47-260 to 269
50F47-60 to 69
50F47-260 to 269
HS780-17NL-304A(b)
―
05-356265-051(a,c)
05-356265-052(a,c)
1,3,4 2,5
―
―
S8910U
S890G1003(f)
S890H1002(f)
1,3,4,5 2
―
―
―
―
1,2 3,4,5
50E47-30 to 39
50E47-230 to 239
―
―
―
1,2,5 3,4
50E47-20 to 29
50E47-220 to 229
―
―
―
1,2,4 3,5
50F47-30 to 39
50F47-230 to 239
―
―
―
1,2,4,5 3
50F47-20 to 29
50F47-220 to 229
―
―
05-356225-151(a,g)
05-356225-152(a,g)
Note: For timing parameters see Table 2.
(a)
The BGH2UNCNTRLHT-01 Universal and the referenced control ignition trial times are different; however, the
ignition trial time is within the design tolerance of the referenced control.
(b)
The BGH2UNCNTRLHT-01 Universal between trial purge time is longer than that of the referenced control.
(c)
The BGH2UNCNTRLHT-01 Universal between trial purge and igniter warmup times is longer than those of the
referenced control.
(d)
The BGH2UNCNTRLHT-01 Universal ignition trial time is shorter than that of the referenced control. Be sure
to observe appliance operation to assure reliable performance.
(e)
The BGH2UNCNTRLHT-01 Universal pre-purge time is longer than that of the referenced control
(f)
The BGH2UNCNTRLHT-01 Universal pre-purge and between trial purge times are longer than those of the
referenced control.
(g)
The BGH2UNCNTRLHT-01 Universal pre-purge, between trial purge, and igniter warmup times are longer
than those of the referenced control.
