4 BG1600M Intermittent Pilot Ignition Control Installation Instructions
1
2
3
4
Power Supply. Provides disconnect means and overload protection as required.
Maximum cable length 48 inches (1,220 mm). (Resistive wire recommended.)
Alternate location for limit controller.
Controls in 24V circuit must not be in ground leg to transformer.
MV/PV
(COM)
PV
GN
D
B
URN
E
R
GND 24V SENSE SPARK
Thermostat
High
Temp
Limit
Pilot
Burner/Ignitor
Flame
Sensor
24VAC
Class 2
Transformer
IN
T
E
R
N
A
L
2 3 4 5 6 8 9 10
1
2
3
4 L1 (Hot)
L2 (Neu)
5
Combination
Gas Valve
TH
7
MV
5 Maximum cable length 48 inches (1,220 mm).
1
Chassis or Frame
Ground
6 Sensor rod must be 3/8” (9.53 mm) to 1/2” (12.7 mm) of the sensor tip should
be in the flame for proper sensing signal.
6
Figure 3: Wiring for 2 Rod Flame Sense without Vent Damper Jumper Plug
1
2
3
4
Power Supply. Provides disconnect means and overload protection as required.
Maximum cable length 48 inches (1,220 mm). (Resistive wire recommended.)
Alternate location for limit controller.
Controls in 24V circuit must not be in ground leg to transformer.
MV/PV
(COM)
PV
GN
D
B
URN
E
R
GND 24V SENSE SPARK
Thermostat
High
Temp
Limit
Pilot
Burner/Ignitor
Flame
Sensor
24VAC
Class 2
Transformer
IN
T
E
RNA
L
2 3 4 5 6 8 9 10
1
2
3
4 L1 (Hot)
L2 (Neu)
5
Combination
Gas Valve
TH
7
MV
5 Maximum cable length 48 inches (1,220 mm).
1
Chassis or Frame
Ground
6 Sensor rod must be 3/8” (9.53 mm) to 1/2” (12.7 mm) of the sensor tip should
be in the flame for proper sensing signal.
Use jumper
plug supplied
with control.
6
Figure 4: Wiring for 2 Rod Flame Sense with Vent Damper Jumper Plug
