Matrix Switcher Series—User Manual
7
3.
Specifications
Hardware
Input Connector
16 x HDMI Type A
Output Connector
16 x HDMI Type A
RS-232 Connector
DB9 Female
LAN Connector
RJ-45
RS-485 Connector
2
2 pins Dip Switcher
1
8 pins Dip Switcher
1
LCD Module
1
Power 100VAC~240VAC, 50/60Hz, internal
Housing Black
Aluminum
Mounting
Rack mountable (3U-rack-mount kits)
Weight 7.5kg
Dimensions (LxWxH)
336x482x130mm
(3U high, full rack wide without grips)
Multimedia
Max. Resolution
1080P@60Hz, 12-bit
Highest TMDS Frequency
225MHz
Control Information
HDMI Cable Distance
At least 10 meter
Baud Rate
9600 bps; 8 data bits, 1 stop bit, no parity
Ethernet Protocol
HTTP, DHCP, TCP/IP, ICMP (ping)
Program Control
Web Server, AVM Application
Serial Control Port
RS-232: 9Pin Female D Type Connector
RS-485: 1X5 Pole Captive Screw
Control Sequence
Matrix
Remote Control
Remote Controller, IR Receiver, IR Blaster
Web Server
LAN, RJ-45
