WWW.ARRMA-RC.COM

© 2013 ARRMA Durango Ltd. A subsidiary of Hobbico, Inc.

5

aEW

Chassis Overview

Front Wheel

and Tyre

Front Lower

Wishbone

Steering Rod

Receiver

Box

ESC (Electronic

Speed Controller)

Rear Shock

Absorber and

Spring

Rear

Wishbone

Motor

Wheel-Nut

Wheel-Nut

Axle

Axle

Hex Hub

Hex Hub

Hinge-pin

Ball-cup

Ball-cup

Rear

Hub Carrier

Hinge-pins

Front

Upright

Steering

Block

Rear Wheel

and Tyre

Camber-link

Driveshaft

Pinion & Spur

Gear Cover

Front Shock

absorber

and Spring

Front Upper

Wishbone

N.B. Vorteks chassis shown as an example - information applies to all variants.

Front

Rear

Safety Instructions for Batteries

1. Use only four(4) AA alkaline batteries in your ATX100 transmitter.

2. Do not dispose of the battery in a fire as it may explode. Check with local codes for
possible special disposal instructions.
3. Do not open or mutilate the battery. Released electrolyte is corrosive and may cause
damage to the eyes and skin. It may be toxic if swallowed.
4. Exercise care in handling batteries in order not to short the battery with conducting
materials such as rings, bracelets and keys. The battery or conduction material may over-
heat and cause burns.

Caution: Risk of explosion

if battery is replaced by an

incorrect type. Dispose of

used batteries according to

the instructions.
