56-Pin Part Pinout
The CY7C64215 enCoRe III device is available in a 56-pin package which is listed and illustrated in the following table. Every port pin
(labeled “P”) is capable of Digital IO. However, Vss and Vdd are not capable of Digital IO.
Table 2. 56-Pin Part Pinout (MLF*)
Pin
No.
Type
Name
Description
CY7C64215 56-Pin enCoRe III Device
Digital Analog
1
IO
I, M
P2[3] Direct switched capacitor block input.
2
IO
I, M
P2[1] Direct switched capacitor block input.
3
IO
M
P4[7]
4
IO
M
P4[5]
5
IO
M
P4[3]
6
IO
M
P4[1]
7
IO
M
P3[7]
8
IO
M
P3[5]
9
IO
M
P3[3]
10
IO
M
P3[1]
11
IO
M
P5[7]
12
IO
M
P5[5]
13
IO
M
P5[3]
14
IO
M
P5[1]
15
IO
M
P1[7] I2C Serial Clock (SCL).
16
IO
M
P1[5] I2C Serial Data (SDA).
17
IO
M
P1[3]
18
IO
M
P1[1] I2C Serial Clock (SCL), ISSP-SCLK.
19
Power
Vss
Ground connection.
20
USB
D+
21
USB
D-
22
Power
Vdd
Supply voltage.
23
IO
P7[7]
24
IO
P7[0]
25
IO
M
P1[0] I2C Serial Data (SDA), ISSP-SDATA.
26
IO
M
P1[2]
27
IO
M
P1[4]
28
IO
M
P1[6]
29
IO
M
P5[0]
Pin
No.
Type
Name
Description
30
IO
M
P5[2]
Digital Analog
31
IO
M
P5[4]
44
IO
M
P2[6] External Voltage Reference (VREF) input.
32
IO
M
P5[6]
45
IO
I, M
P0[0] Analog column mux input.
33
IO
M
P3[0]
46
IO
I, M
P0[2] Analog column mux input and column output.
34
IO
M
P3[2]
47
IO
I, M
P0[4] Analog column mux input and column output.
35
IO
M
P3[4]
48
IO
I, M
P0[6] Analog column mux input.
36
IO
M
P3[6]
49
Power
Vdd Supply voltage.
37
IO
M
P4[0]
50
Power
Vss Ground connection.
38
IO
M
P4[2]
51
IO
I, M
P0[7] Analog column mux input.
39
IO
M
P4[4]
52
IO
IO, M
P0[5] Analog column mux input and column output
40
IO
M
P4[6]
53
IO
IO, M
P0[3] Analog column mux input and column output.
41
IO
I, M
P2[0] Direct switched capacitor block input.
54
IO
I, M
P0[1] Analog column mux input.
42
IO
I, M
P2[2] Direct switched capacitor block input.
55
IO
M
P2[7]
43
IO
M
P2[4] External Analog Ground (AGND) in-
put.
56
IO
M
P2[5]
LEGEND A = Analog, I = Input, O = Output, and M = Analog Mux Input.
* The MLF package has a center pad that must be connected to ground (Vss).
