Siemens Modulating control valves with magnetic actuators, PN16 CA1N4455en
Building Technologies 15.12.2009
If the valve electronics prove faulty, the electronics module must be replaced by the
ASE1 (DN15…32) or ASE2 (DN40…65) replacement electronics module.
Mounting instructions no. 35678 are included.
Always disconnect power before fitting or removing the electronics module.
After replacing the electronics module, calibration must be triggered in order to
optimally match the electronics to the valve (refer to "Calibration", page 5).
Under operating conditions within the limits defined by the application data, the
actuator will become hot, but this does not represent a burn risk. Always
maintain the minimum clearance specified, refer to "Dimensions", page 12.
Disposal Do not dispose of the actuator in domestic waste. This applies in particular to the PCB.
The law may demand special handling of certain components, or it may make
environmental sense.
Observer all current local laws.
Warranty
Observe all application-specific technical data.
If specified limits are not observed, Siemens Switzerland Ltd / HVAC Products
does not assume any responsibility.
Technical data
Functional actuator data
Power supply Extra low-voltage only (SELV, PELV)
Operating voltage AC 24 V +20 / –15 %
Frequency 45...65 Hz
Typical power consumption P
med
Refer to table " Connection type ", page 7
Standby < 2 W (valve closed)
Rated apparent power S
NA
Refer to table " Connection type ", page 7
Required fuse I
N
Slow, refer to table "Wiring connection", page 7
Input Positioning signal Y DC 0/2...10 V or DC 4...20 mA
Impedance DC 0/2...10 V 100 k Ω // 5nF
DC 4...20 mA 100 Ω // 5nF
Forced control YF
Impedance 22 k Ω
Close valve (YF connected to G0) < AC 1 V
Open valve (YF connected to G) > AC 6 V
No function (YF not wired) Positioning signal Y active
Output Position feedback signal X DC 0...10 V; load resistance > 500 Ω
Stroke measurement
Nonlinearity
Inductive
± 3 % of end value
Positioning time < 2 s
Electrical connection Cable entry 2 x ∅ 20.5 mm (for M20)
Connection terminals Screw terminals for 4 mm 2 wire
Minimal wire cross section 1.5 mm 2
Maximum cable length Refer to "Connection type", page 7
Repair
Caution
Caution
