AERCO MXG-461 Series Control Valve - Manufactured by Siemens - Manual (Page 13)

13/14
Siemens Modulating control valves with magnetic actuators, PN16 CA1N4455en
Building Technologies 15.12.2009
Type reference DN Rp
[inch]
G
[inch]
L1 L2 L3 L4 H2 H
min.
E F Weight
[kg]
MXG461.15-0.6
MXG461.15-1.5
MXG461.15-3.0
15 Rp ½ G1B 80 40 42.5 51 240 3.8
MXG461.20-5.0 20 Rp ¾ G 1¼B 95 47.5 52.5 61 260 4.2
MXG461.25-8.0 25 Rp 1 G 1½B 110 55 56.5 65 270 4.7
MXG461.32-12 32 Rp 1¼ G 2B 125 62.5 67.5 76 285
100
5.6
MXG461.40-20 40 Rp 1½ G 2¼B 140 70 80.5 94 320 9.3
MXG461.50-30 50 Rp 2 G 2¾B 170 85 93.5 109 340
150
80 100
11.9
Remarks: • L4: When used as a throughport valve
• Internally threaded Rp... to ISO 7-1
• Externally threaded G...B to ISO 228-1
• Fittings to ISO 49 / DIN 2950
• Also valid for MXG461..P, MXG461..M, MXG461..U
DN B D D2 K L1 L2 L3 H2 H E F Weight Type
reference
∅ ∅ min. [kg]
MXF461.15-0.6
MXF461.15-1.5
MXF461.15-3.0
15 14 95 65 130 65 65 250 5.8
MXF461.20-5.0 20 105 75 150 75 75 260 7.0
MXF461.25-8.0 25
16
115
4x14
85 160 80 80 272 8.0
MXF461.32-12 32 140 100 180 90 90 285
100
11.0
MXF461.40-20 40
18
150 110 200 100 100 322 15.4
MXF461.50-30 50 165 125 230 115 105 340 19.8
MXF461.65-50 65
22
185
4x18
145 290 145 125 392
150
80 100
28.6
Remarks: • Counter-flanges must be supplied by the installer!
• Flange dimensions to ISO 7005-2
• Also valid for MXF461..P, MXF461..M, MXF461..U
MXF461..
flanged valves
