12/14
Siemens Modulating control valves with magnetic actuators, PN16 CA1N4455en
Building Technologies 15.12.2009
Piping must be connected to potential earth!
Factory setting: Valve characteristics equal-percentage, positioning signal DC 0...10 V.
Details see "Configuration DIL switches", page 4.
See "Calibration", page 5.
Application examples
The examples shown below are basic diagrams with no installation-specific details.
The valve may only be used as a mixing or through-port valve, not as a diverting
valve. Observe the direction of flow!
B
A
B
AB
B
A
A
AB
B
A
C D E
AB
10
x
D
N
[
m
in.
0.
5
m
]
44
61
Z
17
AB
B
A
A
AB
Mixing circuit Mixing circuit with
bypass (underfloor
heating system) Injection circuit Diverting circuit Injection circuit
with throughport
valve
Dimensions
Dimensions in mm
Warning
DIL switch
Calibration
Hydraulic circuits
Caution
MXG461..
threaded valves
