5.3 THE TOUCH SCREEN NAVIGATION LOGIC SEQUENCE

The AERCO Boiler Valve Controller is operated by making use of the front panel touch screen.

See Figure 1. As previously mentioned, It should be noted that the five buttons labeled F1

through F5 appearing below the touch screen are for future use only and are not currently

operational. The touch screen’s logical sequence for valve control is illustrated in Figure 12. A

description of the operational sequence follows for a 4 boiler system. It is illustrated in Figures

13 and 14. A 12 boiler system utilizes a similar operational sequence.

When the AERCO Boiler Valve Controller is operating, users will find themselves initially on the

Main Screen as illustrated in Figure 13, screen 1.
From the Main screen the user will be able to press either of two touch screen buttons (“TIMER”

or “VALVES”) as well as see indications as to which boilers (if any) are firing and which valves

(if any) are open. The TIMER component of the BVC will be discussed subsequently in Section

5.5. Assume that the user presses the “VALVES” touch screen button. This action takes the

user to the Valves screen, Figure 13, screen 2.
From the Valves screen the user may press either the “Valves 1-2” touch screen button, the

“Valves 3-4” touch screen button, as well as a “BACK” touch screen button. The latter brings the

user back to the Main screen while the “Valves 1-2” and “Valves 3-4” touch screen button bring

the user to screens that involve the valves associated with their respective touch screen button

labels. Let us now assume that the user presses the “Valves 1-2” touch screen button.
Assume that the user now navigates to the “Valves 1-2” screen. This screen contains two area

boxes, one for Valve 1 and one for Valve 2, as well as a “BACK” touch screen button. Pressing

the latter brings the user back to the Valves screen. Each area box contains a pair of touch

screen option buttons, labeled “OPEN” and “CLOSED”. Pressing the touch screen button

currently not chosen will select the other value for the valve open/closed state. For instance, if

Valve 1 is currently “OPEN” pressing the “CLOSE” touch screen button for that particular valve

will close the valve (

NOTE: If a boiler is firing, the corresponding valve cannot be moved to the

“CLOSED” position.); if Valve 1 is currently “CLOSED” pressing the “OPEN” touch screen button

for that particular valve will open the valve
