A&D Weighing FX-300i-PT - Manual (Page 19)

17
MAX / MIN
ON / FAST AUTO-OFF
1
2
3
4
5
6
7
8-3 Using the Thermometer
Part names
Front Back
1: LCD
2: ON/FAST button
3: MAX/MIN button
4: Sensor sheath
5: AUTO-OFF button
6: Sheath protector
7: Battery cover
Before use
One LR-44 battery is provided with the thermometer. It is for testing the performance of the
thermometer and may have a limited life. Before use, install the battery as described in “Replacing
the battery” below.
Replacing the battery
When the LCD becomes blurred, replace the battery as follows.
1. Place the thermometer on a table with the back
up. Using a coin, rotate the battery cover
anti-clockwise to remove it.
2. Remove the old battery.
3. Install a new battery, with the + side (flat side)
facing up.
4. Using the coin, reattach the battery cover.
NOTE
• Be sure to face the + side up when installing a battery.
• Use the specified battery only.
• Do not disassemble, heat, short-circuit, dispose of in fire or attempt to recharge the
battery. It may explode or leak and cause personal injury.
• Keep the battery out of the reach of children. If swallowed, consult a physician
immediately.
• Follow the local regulations when disposing of a used battery.
• To keep the thermometer watertight, do not damage the rubber ring or remove it
from the battery compartment.
Coin
Battery cover
Battery (LR-44)
