A-190 MIDI-CV/SYNC Interface System A - 100 doepfer
6
Pressing the Group button 1 switches to the other
menu group - the button acts as a toggle switch. A
mini-light-show indicates which group is selected:
For example, if, after switching on, you need to alter
GATE POLARITY in Config Menu 1, press the Group
button 1 once. The light sequence goes upwards
from the bottom LED, and tells you that when you
press the edit button you will be in the Config Menu.
Changing to edit mode
When in performance mode, switch over to edit mode
by pressing the MENU button 2. The top LED flas-
hes, to tell you that you’re in edit mode, and can now
access the parameters in the first menu in the group
you selected with the group button:
You can tell which menu group you’re in by checking
the speed at which the LED (8) blinks:
slow blink : Config menu
fast blink : Performance menu
H (Symbols in the text:
0
: slow
2
: fast)
Menu selection
If the parameter you want to edit isn’t in the first menu,
scroll through the other menus by repeatedly pressing
the MENU button 2 (see the diagram on the next
page).
Performance
Menu Config
Menu
Sequence of lights
Sequence of lights
Edit Mode, Menu 1
