doepfer

System A - 100

MIDI-CV/SYNC Interface

A-190

3

In / Outputs

!

MIDI THRU : Output for relaying MIDI messages

sent to MIDI IN to another MIDI unit.

"

MIDI IN :

Input for MIDI messages.

§

Clock :

MIDI clock signal (or divided version)
output.

$

Reset :

Reset signal output:-
MIDI-Start or Continue): low voltage
MIDI-Stop: high voltage.

%

GATE :

GATE signal output; normally connec-
ted internally to the A-100 system bus
(INT.GATE line), but can be dis-
connected.

&

CV 1 :

Output for control voltage 1 (D/A
converter 1); normally connected in-
ternally to the A-100 system bus (INT.
CV line), but can be disconnected.

/

CV 2 :

Output for control voltage 2 (D/A
converter 2).

H

N.B.:

On the front panel of the first
production series , the arrows
were accidentally printed the
wrong way round.

In these instructions, though,
all the functions, for instance
selecting a menu group, are
described correctly (see p.

6).

Channel

CV 1

Group

Perform.

Config.

Ч

Ш
