Doepfer A-190-1 MIDI-CV/Gate/Sync Interface - Manual (Page 16)

A-190 MIDI-CV/SYNC interface System A - 100 doepfer
16
No function at present
Reserved for future expansion (e.g. arpeggiator)
BEND WIDTH
The BEND WIDTH parameter sets the pitch bend
range. For example, if you set the range to a whole
tone, the pitch bender on your MIDI instrument will
alter the A-100’s VCO pitch by a maximum interval of
a semi-tone up or down.
M M M M The pitch bend range is set by the interval
between two MIDI notes played in succes-
sion:
Reference note: set by the first NOTE ON
Range note: set by the second NOTE ON
Any channel can receive the message.
[m m m m Set the pitch bend range
]
Performance Menu 5
Arpeg.
2
Performance Menu 6
Bend W.
2
