Page 30 Pocket Electronic User's Guide
00 ~ 10 Parameter 1. There are 16 data bytes setting the MIDI channel of each knob, a setting of
0 sets the knob to the Master Channel.
00 ~ 7F Parameter 2. There are 16 data bytes setting the event type for each knob, a setting of
7F defines “No Event” to the knob
00 ~ 7F Parameter 3. There are 16 data bytes setting the additioanl event data for each knob. The
definition of parameter 3 depends on what parameter 2 is set to.
F7 EOX (End of System Exclusive)
The data that must follow is the Single Store message which is:
F0 00 20 20 14 00 30 F7:
F0 Sys-Ex byte
00 European Sub ID
20 Doepfer Sub ID 1
20 Doepfer Sub ID 2
14 Device “Pocket Series"
00 reserved
30 Command Byte “Single Store”
00 ~ 7F Preset Number (Must be the same as in the first message above)
00 reserved
F7 EOX (End of System Exclusive)
Parameter Tables
Parameter 1: MIDI Channel
00 Master Channel
01 ~ 10 MIDI Channels 1 ~ 16
11 ~ 7F values undefined (decimal values 17 - 127)
Parameter 2: Event Definition
Decimal Hex Definition
0 00 Controller
1 01 Pitch Bend
2 02 Mono Aftertouch
3 03 Program Change
4 04 Poly Aftertouch
5 05 Note On
6 06 Note Off
7 07 free
8 08 RPN0 MSB
9 09 RPN0 LSB
10 0A RPN1 MSB
11 0B RPN1 MSB
12 0C free
13 0D free
14 0E RPN127 MSB
15 0F RPN127 LSB
16 10 NRPN0 MSB
17 11 NRPN0 LSB
18 12 NRPN1 MSB [XG Multi / GS]
19 13 NRPN1 LSB [XG Multi / GS]
20 14 NRPN8 MSB
21 15 NRPN8 LSB
22 16 NRPN9 MSB
23 17 NRPN9 LSB
