User's Guide Pocket Electronic Page 19
Input 5 LFO 1 to Volume Coarse
Input 6 LFO 1 to Cutoff Coarse
Input 7 Env 1 to Cutoff Coarse
Input 8 undefined
Input 9 Master Tuning Fine
Input 10 LFO 1 to Pitch Fine
Input 11 LFO 2 to Pitch Fine
Input 12 Env1 to Pitch Fine
Input 13 LFO 1 to Volume Fine
Input 14 LFO 1 to Cutoff Fine
Input 15 Env 1 to Cutoff Fine
Input 16 undefined
Preset 22 AWE/SB 5 NRPN/Controller Masterchannel
Input 1 Filter Cutoff Coarse NRPN
Input 2 Filter Resonance Coarse NRPN
Input 3 Modulation Controller1
Input 4 Reverb Send Coarse NRPN
Input 5 Chorus Send Coarse NRPN
Input 6 Portamento Controller5
Input 7 Balance Controller8
Input 8 Expression Controller11
Input 9 Filter Cutoff Coarse NRPN
Input 10 Filter Resonance Coarse NRPN
Input 11 Mono Aftertouch MonoAftertouch
Input 12 Reverb Send Fine NRPN
Input 13 Chorus Send Fine NRPN
Input 14 Portamento Off/On Controller65
Input 15 Pan Controller10
Input 16 Volume Controller7
Presets 23 ~ 28 control the drum kit, which would normally require the master channel to be set to channel 10. The
knobs all relate to the same drums on these presets as shown below, with each preset controlling Pitch, Level,
Pan, Reverb Send, Chorus Send or Delay/Var. Send depending on the preset selected.
Preset 23 GS/XG Drum Pitch NRPN Masterchannel
Preset 24 GS/XG Drum Level NRPN Masterchannel
Preset 25 GS/XG Drum Pan NRPN Masterchannel
Preset 26 GS/XG Drum Reverb NRPN Masterchannel
Preset 27 GS/XG Drum Chorus NRPN Masterchannel
Preset 28 GS/XG Drum Delay/Var NRPN Masterchannel
Presets 29 ~ 32 control the drum kit, which would normally require the master channel to be set to channel 10. The
knobs all relate to the same drums on these presets as shown above, with each preset controlling Filter Cut Off,
Filter Resonance, Envelope Attack or Envelope Decay depending on the preset selected.
Preset 29 XG Drum Cutoff NRPN Masterchannel
Preset 30 XG Drum Reson. NRPN Masterchannel
Preset 31 XG Drum Attack NRPN Masterchannel
Preset 32 XG Drum Decay NRPN Masterchannel
Input 1 Bass Drum Pitch 9 Bongo Pitch
Input 2 Snare Drum Pitch 10 Conga Pitch
Input 3 Tom Pitch 11 Timbale Pitch
Input 4 Hi-Hat Pitch 12 Hi Q Pitch
Input 5 Hand Clap Pitch 13 Seq Click Pitch
Input 6 Rim Shot Pitch 14 Finger Snap Pitch
Input 7 Crash Pitch 15 Click Noise Pitch
Input 8 Ride Pitch 16 Tambourine Pitch
