Pocket Electronic
User's Guide
Switch
12345678
No. Preset Explanation
Switch
12345678
No. Preset Explanation
00000000 1
Volume Channel 1 - 16
00000100 33
XG Level Chn 1 - 16
10000000 2
Panorama Channel 1-16
10000100 34
XG Pan Chn 1 - 16
01000000 3
Cutoff Channel 1-16
01000100 35
XG Reverb Chn 1 - 16
11000000 4
Resonance Chan. 1-16
11000100 36
XG Chorus Chn 1 - 16
00100000 5
Volume/Pan Ch.1 - 8
00100100 37
XG Dry Chn 1 - 16
10100000 6
Volume/Pan Ch.9 - 16
10100100 38
XG Var Chn 1 - 16
01100000 7
Cutoff/Reson. Ch.1-8
01100100 39
XG Low EQ Gain Chn 1 - 16
11100000 8
Cutoff/Reson. Ch.9-16
11100100 40
XG Low EQ Chn 1 - 16
00010000 9
Ctrl 0-15 Masterchn
00010100 41
XG High EQ Gain Chn 1 - 16
10010000 10
Ctrl 16-31 Masterchn
10010100 42
XG High EQ Chn 1 - 16
01010000 11
Ctrl 32-47 Masterchn
01010100 43
XG Mpart-Effect Masterchn
11010000 12
Ctrl 48-63 Masterchn
11010100 44
XG Level AD1/2,W1-12
00110000 13
Ctrl 64-79 Masterchn
00110100 45
XG Pan AD1/2,W1-12
10110000 14
Ctrl 80-95 Masterchn
10110100 46
XG Reverb AD1/2,W1-12
01110000 15
Ctrl 96-111 Masterchn
01110100 47
XG Chorus AD1/2,W1-12
11110000 16
Ctrl 112-127 Masterchn
11110100 48
XG Var AD1/2,W1-12
00001000 17
GS/XG Masterchn
00001100 49
XG Dry AD1/2,W1-12
10001000 18
AWE/SB 1 Masterchn
10001100 50
XG EQ
01001000 19
AWE/SB 2 Masterchn
01001100 51
XG Reverb
11001000 20
AWE/SB 3 Masterchn
11001100 52
XG Chorus
00101000 21
AWE/SB 4 Masterchn
00101100 53
XG Variation
10101000 22
AWE/SB 5 Masterchn
10101100 54
XG Insertion 1
01101000 23
GS/XG Drum Pitch
01101100 55
XG Insertion 2
11101000 24
GS/XG Drum Level
11101100 56
GS Reverb/Chorus
00011000 25
GS/XG Drum Pan
00011100 57
Strings
10011000 26
GS/XG Drum Reverb
10011100 58
Rebirth Mchn
01011000 27
GS/XG Drum Chorus
01011100 59
CS1x Masterchn
11011000 28
GS/XG Drum Delay/Var
11011100 60
Waldorf Pulse Mchn
00111000 29
XG Drum Cutoff
00111100 61
ASR-X Masterchn
10111000 30
XG Drum Reson.
10111100 62
Doepfer MAQ 1 Mchn
01111000 31
XG Drum Attack
01111100 63
Doepfer MAQ 2 Mchn
11111000 32
XG Drum Decay
11111100 64
K5000 MCB10 Mchn
Switch
12345678
No. Preset Explanation
Switch
12345678
No. Preset Explanation
00000010 65
Yamaha Promix Mchn
00000110 97
10000010 66
ProFive Osz/LFO
10000110 98
01000010 67
ProFive Mix/Filt./ADSR
01000110 99
11000010 68
Cubase VST Vol 1-16
11000110 100
00100010 69
Cubase VST Pan 1-16
00100110 101
10100010 70
Cubase VST Vol/Pan 1-8
10100110 102
01100010 71
B4 Console/TubeAmp/Pedal
01100110 103
11100010 72
B4 Rotator
11100110 104
00010010 73
B4 Upper Manual 1
00010110 105
10010010 74
B4 Upper/Lower 1
10010110 106
01010010 75
Sherman Filterbank Chn16
01010110 107
11010010 76
Sherman Filterbank Mchn
11010110 108
00110010 77
00110110 109
10110010 78
10110110 110
01110010 79
01110110 111
11110010 80
11110110 112
00001010 81
00001110 113
