EZT ® 5
TEcHnical spEcificaTions
Technical specifications for the EZT ® are listed in Table 1.
Table 1. Technical Specifications
input speeds weight of unit
Maximum: 3000 RPM 29 lbs. (13 Kg)
Minimum: 1800 RPM
Table 2. EZT component options
Figure 3. Configuration Label
producT idEnTificaTion
The model and configuration of the EZT can be determined from the label shown in Figure 3.
component component options
axle shaft diameter and End options: 1˝ Flange 1˝ DD
Brake location: Inboard Outboard
Brake Type: Cog Disc
control arm location: Inboard Outboard
control arrangements: Standard Control Arm RTN (scissor style)
overall Transaxle reduction: 19.2:1 21.2:1
