12

EZT

®

sEcTion 5. rEpair

How To usE THis Manual

Each subassembly illustrated in this section is

illustrated with an exploded view showing the

parts involved. The

item reference numbers

in each illustration are for assembly instruc-

tions only. See page 31 for part names and

descriptions. A complete exploded view and

item list of the transaxle is provided at the end

of the repair section.

gEnEral insTrucTions

Cleanliness is a primary means of assuring

satisfactory life on repaired units. Thoroughly

clean all exposed surfaces prior to any type

of maintenance. Cleaning of all parts by us-

ing a solvent wash and air drying is usually

adequate. As with any precision equipment,

all parts must be kept free of foreign material

and chemicals.
Protect all exposed sealing surfaces and open

cavities from damage and foreign material. The

external surfaces should be cleaned before

beginning any repairs.
Upon removal, it is recommended that all seals,

O-rings, and gaskets be replaced. During

installation lightly lubricate all seals, O-rings

and gaskets with a clean petroleum jelly prior

to assembly. Also protect the inner diameter of

seals by covering the shaft with a cellophane

(plastic wrap, etc.) material.

Parts requiring replacement must be replaced

from the appropriate kits identified in the Items

Listing, found at the end of this manual. Use

only original Hydro-Gear

®

replacement parts

found in BLN-51427 (CD).
iMporTanT: When internal repair is per-

formed on the EZT

®

, the filter assembly must

be replaced.

TransaXlE rEMoval

It is necessary to remove the EZT from the ve-

hicle before performing the repair procedures

presented in this section.

noTE: if removing the wheel from the

transaxle, do so by removing the four (4)

lug nuts. do not remove the axle/hub nut.

liMiTEd disassEMBlY

The following procedures are presented in

the order in which they must be performed to

completely disassemble the unit. Do not disas-

semble the unit any farther than is necessary

to accomplish the required repairs. Each disas-

sembly procedure is followed by a correspond-

ing assembly procedure.
Reassembly is accomplished by performing

the “Assembly” portions of the procedures. If

the unit has been completely disassembled, a

summary of the assembly procedures, in the

order in which they should occur, is given on

page 29.
