EZT ® 33
EZT ® iTEMs lisT
no. dEscripTion
1 ASSEMBLY, MAIN HOUSING
BUSHING
2 ASSEMBLY, SIDE COVER
BUSHING
3 PLATE, BYPASS
4 ASSEMBLY, PUMP BLOCK
BLOCK, CYLINDER
PISTONS
SPRINGS, COMPRESSION
WASHERS, THRUST
5 SPACER
6 ASSEMBLY, MOTOR BLOCK
7 PLUG, 9/16-1
8 PIN, STAINLESS, HEADLESS
9 HFHCS 1/4-20 X 1.25 (SELF-TAPPING)
10 SEAL, LIP
12 BOLT, HEX FLANGE 3/8-24 X 2.5
13 SEAL, LIP
14 RING, RETAINING
15 ROD, BYPASS
16 RING, RETAINING
17 ARM, BYPASS
18 RING, RETAINING (PUSHNUT)
19 SWASHPLATE, TRUNNION, MACHINED
20 SEAL, LIP
21 STUD
22 WASHER
23 ARM, CONTROL
24 WASHER, FLAT
25 TWHCS 5/16-24 X 1.0
26 NUT, HEX LOCK 5/16-24 UNJF
27 SPRING-HELICAL COMPRESSION
28 WASHER
29 SHAFT, INPUT
30 BEARING, BALL
31 RING, RETAINING WIRE
32 SPACER
33 SEAL, LIP
34 RING, RETAINING
35 BEARING, THRUST
36 WASHER, FLAT
37 RING, RETAINING
38 GEAR, PINION, 13T
39 SHAFT, MOTOR
40 WASHER, MOTOR SHAFT
41 WASHER, HT
42 GEAR, 10T/48T
43 GEAR, 10T JACKSHAFT
44 PIN, JACKSHAFT
45 RING, SPIRAL RETAINING
46 GEAR, 52T BULL
47 WASHER
48 BEARING, SLEEVE (INBOARD)
49 AXLE
50 BUSHING
51 SEAL, LIP
52 KIT, SEAL
53 KIT, EXPANSION PLATE
54 KIT, FAN-PULLEY
no. dEscripTion
55 KIT, BRAKE ASSEMBLY
56 CHECK PLUGS
57 KIT, CENTER SECTION-FILTER
59 KIT, BYPASS ARM
60 ASSEMBLY, COVER
61 KIT, FILTER
62 FILTER, BASE
63 CENTER SECTION
64 MAGNET
65 SCREW, 10-32 X 1/2 (SELF-TAPPING)
66 HOUSING, MAIN
67 PLATE, EXPANSION
68 COVER, SIDE
70 PIN, CLEVIS
71 BUSHING
72 WASHER
73 SCREW
74 ARM, BRAKE
75 SPRING
99 NUT, PIN LOCKING
100 ROTOR
119 HUB
120 FAN
121 PULLEY
122 NUT, HEX LOCK
123 WASHER OR CAPSCREW 1/4-20
124 HUB KIT
126 FITTING
127 HOSE, EXPANSION TANK
128 CAP, BARBED VENT
130 NUT, HEX 1/4-20
131 SPACER OR CAPSCREW 5/16-20 X 1
134 WASHER
135 SPRING
138 KIT, BREATHER ASSEMBLY
139 KIT, BREATHER ASSEMBLY
140 ARM, NEUTRAL
141 RTN
144 DEFLECTOR, BELT
150 PUCK, BRAKE
151 PLATE, PUCK
153 ASSEMBLY, BRAKE YOKE
154 SPACER
155 PIN, BRAKE
156 SPRING, BRAKE COMPRESSION
157 CAPSCREW, 1/4-20 X 2.0
158 WASHER
159 NUT, CASTLE 5/16-24
160 PIN, COTTER
200 KIT, RTN
