EZT ® 13
Table 5. required Tools
Miscellaneous
EZT ® Service & Repair Manual
Flat Blade Screw Driver (2)
Torque Wrench
Air Impact Wrench
Rubber Mallet
Breaker Bar
Side Cutters/Snips
pliers
Needle Nose
Large External Snap Ring
Small Internal Snap Ring
Tools and TorQuEs
sockets
1/2”-3/8” Adapter
3/8” Deep
1/2” Deep
7/16” Deep
9/16” Deep
3/4” Deep
13/16” Deep
7/8”
T-25 Torx Head
T-40 Torx Head
Apex AN-08
Table 6. required Torque values
operation Torque item description
Metal Plug 180-240 lb-in [20-27 Nm] 7 Plug 9/16-18
Side Housing Screws 105-155 lb-in [12-17 Nm] 9 Screw 1/4-20 x 1.25
Center Section Bolts 525-700 lb-in [60-80 Nm] 12 Screw 3/8-24 x 2.5
Control Arm Stop Stud 50-120 lb-in [6-18 Nm] 21 Stud 5/16-24
Control Arm Screw 230-310 lb-in [26-35 Nm] 25 Screw 5/16-24 x 1
Stop Stud Nut 85-120 lb-in [10-14 Nm] 26 Nut, Lock 5/16-24 UNF
Check Plugs 280-400 lb-in [32-45 Nm] 56 Check Plug Assembly
Expansion Plate Screws 25-50 lb-in [3-6 Nm] 65 Screw 10-32 x 0.50
Brake Assembly Screw 80-120 lb-in [9-14 Nm] 73 Screw 1/4-20 x 1
Hub Locknut 240-260 lb-ft [271-298 Nm] 99 Nut, Hex 3/4-16 Lock
Fan/Pulley Lock Nut 360-520 lb-in [41-59 Nm] 122 Lock Nut 1/2 x 20
Breather Fitting 180-240 lb-in [20-27 Nm] 126 Fitting 9/16
RTN Adjustment Screw 175-200 lb-in [19-22 Nm] 131 Screw 5/16-24 x 1
Disc Brake Screw 80-120 lb-in [9-14 Nm] 157 Screw 1/4-20 x 2
