Digital Video Recorder User Manual
10
Item Name Description
1 Spot out
Connect to monitor as an AUX output channel by channel. Only video display, no menu
show
2 Audio in 16 CH Audio input
3 Audio out Audio output, connect to the sound box
4 S-video S-Video output, connect to monitor
5 MIC IN Talk
6 USB MOUSE Only for USB mouse
7 PS/2 port Connect to PS/2 mouse
8 VGA port VGA output, connect to monitor
9 RS232 For debug
10 LAN Network port
11 ALARM IN Connect to external sensor1-16
12 RS485 Connect to speed dome
13 ALARM OUT Relay output1-4. Connect to external alarm.
14 + 5V and GND +5 V and Grounding
15 FAN For cooling the device
16 POWER INPUT AC 110Vor 110V
17 POWER SWITCH Power on/off
18 Loop out For outputting each channel’s image independently
19 e-SATA Connect to HDD for backup
20 Video in Video input channels from 1-16
21 Video out Connect to monitor
Tab 2.4 Definition of Rear Interface
2.4 Remote Controller
It uses two AAA size batteries and works after loading batteries as following:
STEP1 Open the battery cover of the Remote Controller
STEP2 Place batteries. Please take care the poles (+ and -)
STEP3 Replace the battery cover
