Digital Video Recorder User Manual
105
Appendix F DVR Specifications for 16-channel DVR
Compression format Standard H.264 Baseline
Video output Composite：1.0V p-p/75Ω，BNC×2 S-VIDEOX1, VGAX1
Video input Composite：1.0V p-p/75Ω，BNC×16
Display Resolution 720*576 (PAL), 720*480 (NTSC)
Record Resolution 704*576 (PAL), 704*480 (NTSC)
Display Frame Rate 400FPS (PAL), 480FPS (NTSC)
Record Frame Rate 400FPS (PAL) , 480FPS (NTSC)
Audio input RCA X16
Audio output RCA X1
Alarm input NO or NC 16CH
Alarm output 4CH
Record Mode Manual / Sensor /Timer / Motion detection
Simplex/Duplex/Triplex Pentaplex
Network Interface
RJ45 (LAN, INTERNET)
PTZ control YES
Communication interface
RS485, USB2.0 x 2(one for backup, another for USB mouse), PS/2 x 1,
1CH MIC INPUT
Hard disk info SATA x 3+DVD-RW x 1 or SATA ×8
Remote controller YES
Power supply AC 220V or 110V
