Digital Video Recorder User Manual
7
Item Name
Description
1 SPOT
OUT
Connect to monitor as an AUX output channel by channel. Only video display, no
menu show
2
AUDIO OUT
Audio output, connect to the sound box
3
S-VIDEO
S-Video output, connect to monitor
4
PS/2 port
Connect to PS/2 mouse
5
USB MOUSE
Only for USB mouse
6
RJ45 port
Connected to internet
7
VGA port
VGA output, connect to monitor
8 RS232
For
debug
9
ALARM IN
Connect to external sensor1-4, 5-16 reserved
10
RS485
Connect to speed dome
11
ALARM OUT
Relay output1-4. Connect to external alarm.
12
+5V and GND
+5 V and Grounding
13
AUDIO IN
4CH AUDIO input
14
FAN
For cooling the device
15
POWER INPUT
AC 110Vor 110V
16
VIDEO OUT
Connect to monitor
17
VIDEO INPUT
4CH VIDEO input
18
E-SATA
Connect to HDD for backup
19 POWER
SWITCH
Switch
on/off
Tab 2.2 Definition of Rear Interface
