Digital Video Recorder User Manual
5
Fig 2.1 Front Panel
Item Name Function
1 Multi-screen button Change screen display like single, 4, 8 ,and 16 screens
2 10+ Input number 10 and the above number together with other digital keys.
3 MENU Enter menu in live
4 BACKUP Enter backup mode in live
5 P.T.Z Enter PTZ mode in live
6 AUDIO Control voice
7 Enter button To confirm the choice or setup
8 INFO Check recording data
9 Direction Direction buttons. Move cursor in setup or pan/title PTZ
10 REW Rewind
11 PLAY Enter play interface
12 Shuttle Control the speed of playback
13 STOP Quit playback mode
