Page 34: 4 mask
Digital Video Recorder User Manual
interface.
34
Step1: enter into system configurationÆlive configurationÆSPOT; refer to Fig 4-9:
4.2.3 SPOT
Fig 4-9 live configuration-SPOT
itch
spl
Step2: select split mode: 1×1and channel
Step3: dwell time: the time interval for a certain dwell picture display sw
ing to next dwell picture display
Step4: selected the
it mode, then setup current picture group. Click
button to setup the previous channel groups of
dwell picture, click
button to set the latter channel groups of dwell picture.
Step5: click “default” button to resort default setting; click “apply” button to save the setting; click “exit” button to exit current
terface
ser can setup private mask area on the live image picture, max threes areas.
in
4.2.4 Mask
U
