COP-USA DVRHRT-16MD User Manual
Page 17
Digital Video Recorder User Manual
17
Item
Name
Description
1
Video out
Connect to monitor
2
Video in
Video input channels from 1-16
3
E-SATA
Connect to HDD for backup
4
LOOP OUT
For outputting 1-16ch image independently
5 Spot
out
Connect to monitor as an AUX output channel by channel.
Only video display, no menu show
6
Audio out
Audio output, connect to the sound box
7 MIC
IN
Talk
8
HDMI port
Connect to high-definition display device
9
VGA port
VGA output, connect to monitor
10
Audio in
16 CH Audio input
11 USB
port
To connect external USB devices like USB flash, USB HDD
for backup or update firmware; or connect to USB mouse
12 LAN
Network
port
13
ALARM IN
Connect to external sensor1-16
14
ALARM OUT
4ch relay output. Connect to external alarm.
15
P/Z
Connect to speed dome
16
K/B
Connect to keyboard
17 GND
Grounding
18
FAN
For cooling the device
19
POWER INPUT
AC 110Vor 110V
20
POWER
SWITCH
Switch on/off
Tab 2.3 Definitions of Rear Panel Buttons
