DVR User Manual
22
4.3.1 Enable
Step1: Enter into MenuSetupRecordEnable tab. Refer to Fig 4-11:
Fig 4-11 Enable Record
Step2: Checkmark record and audio.
Step3: Select All to setup the same settings for all channels.
4.3.2 Record Bitrate
Step1: Enter into MenuSetupRecordRecord bit rate interface. Refer to Fig 4-12:
Step2: Setup rate, resolution, quality, encode and max bit stream
Step3: Select “All” to set same settings for all channels.
Step4: Click “default” button to restore default setting; click “apply” button to save the setting; click “exit” button to exit current
interface.
Note: If the rate value set is over high the maximum resources of the device, the value will be adjusted automatically.
Parameter Meaning
Record To enable/disable recording
for the channel
Audio To enable/disable audio
recording for the channel
