4/8/16DVR Quick Start Guide
3
3. Power on
Step1: Connect with the source power; switch on the power button near the
power port on the rear panel
Step2: The device will boot, and the power indicator will display blue
Step3: A WIZZARD window will be pop-up and show some information about
time zone，time setup，network configuration, record configuration and disk
management. User can setup here and refer to the concrete setup steps from
the corresponding chapters. If users don‟t want to setup Wizard, please click
Exit button to exit.
Notice: This DVR can only display options on either VGA monitor or BNC monitor at
a given point of time, if there is live image display without menu options then
please check if there is display on other device/monitor, or long press ESC key to
wait for login dialog box to appear. Long press ESC key can switch the output
between BNC and VGA.
4. Basic setup
4.1 Accessing the DVR menus
4.1.1 Login
Press the MENU button which will bring the LOGIN dialogue box and enter the
user name: admin and password: 123456
Fig 4-1 Login
4.1.2 Main menu setup
Click right mouse, or press ENTER button on the front panel to enter into the
main menu. Then click Setup to enter into Setup interface as shown in Fig 4-2.
Fig 4-2 Main menu setup
Basic configuration: Users can set video system, menu language, audio, time
