DVR User Manual
18
4.2 Live Configuration
Live configuration includes two submenus: live and main monitor.
4.2.1 Live
In this tab, user can setup camera name.
Step1: Enter into MenuSetupLiveLive tab. Refer to Fig 4-6:
Note: A soft keyboard will pop up by clicking the camera name. User can self-define the
camera name.
Step2: Checkmark the Show Name when you set your camera name.
Click “Default” button to restore the default setting, click “OK” button to save the
setting.
Step3: Select “All” to setup the same settings for all channels. Fig 4-6 Live ConfigurationLive
4.2.2 Main Monitor
Step1: Enter into MenuSetupLiveMain Monitor tab. Refer to Fig 4-7:
Step2: Select split mode: 1Ч1, 2Ч2 and channel. Click button to setup the
previous channel group. Click button to set the latter channel group.
Step3: Set the dwell time.
Step4: Click “Default” to restore default setting; click “Apply” to save the setting;
click “Exit” to exit the current tab.
Fig 4-7 Live Configuration-Main Monitor
4.3 Record Configuration
Record configuration includes six sub menus: enable, record bit rate, time, recycle record, stamp and snap.
