DVR User Manual
6
Name Description
P.T.Z. button Enter PTZ mode in live
Audio button Enable the audio in live
REC button Record manually
Play/Pause button Play or pause the record
REW button Rewind key
FF button Fast forward
Exit button Exit the current interface or status
Screen mode button Choose single, four or multiple channel modes
IR For remote controller
USB port
To connect external USB devices like USB flash, USB HDD for
backup or update firmware; or connect to USB mouse
2.3 Rear Panel Instructions
Fig 2.3 Rear Panel for 8-CH
