Browse analysis results – ChemoMetec NC-3000 User Manual
Page 25
991-3003 Rev. 1.0
August 2013
25
Browse Analysis Results
Buttons
In the upper right corner launches the
to browse images from a specified date range (day,
week, month or year).
Marks the row for the selected file for which the image and extended results are displayed.
Click on this button to select the file acquired in this chamber.
Return to ‘acquisition mode’ to run a new analysis, when the instrument is connected.
This button inserts or ejects the sample tray.
This button allows the user to export the results for all the files for the shown slide or cassette as a
CSV file.
File list:
Click on a file in the data folder to browse the results of a previously acquired file. The file will be
opened and the image will be displayed. Optionally files acquired within the same slide may be
selected by clicking on the arrow in the desired chamber.
