Checkline TD-1-TE User Manual
Checkline Sensors

-1-
1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
0
2
1.1 Complete Kit
2.0 Overview of Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
0
3
3.0 Removing/Replacing Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
0
3
4.0 Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
0
4
4.1 Setting Decimal Point
4.2 Setting the Low Alarm Limit
4.3 Setting the High Alarm Limit
4.4 Enabling & Disabling Electronic Damping
5.0 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
0
6
6.0 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
0
7
6.1 Zero Adjustment
6.2 Gain Adjustment
6.3 Checking the Calibration
7.0 Analog Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11
7.1 Changing Analog Output Type
7.2 Zero and Gain Adjustments
8.0 Technical Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
15
8.1 TD-1-TE Specifications
8.2 Pin Assignments
8.3 On-Line Sensor Specifications
9.0 Warranty
T
ABLE OF
C
ON T EN T S
-16-
8.3 Online Sensor Specifications
Series TS (Models TS1, TSP, TSH, TSL,TSF, TSB1, TSB2)
Calibration:
According to Electromatic factory procedure
Accuracy:
For 10% to 100% of range: ± 1 % full scale
Remainder of
range and other
calibration material
3% full scale or better
Overload protection
100% of range
Measuring principle
Strain gauge bridge
Measuring roller
deflection
0.5 mm, max.
Signal processing
Analog
Output signal:
0 - 1 V DC (standard)
Damping (fg)
Standard: 30 Hz (other values on request)
Temperature
coefficient:
Gain: less than ± 0.01% full scale / °C
Temperature range
10 – 45 °C
Air humidity
85% RH, max.
Power supply
Standard: 12 to 18 VDC (21 mA) (regulated)
